Let’s imagine we want to build a To-Do List Application where users can:

• Add tasks to their list.
• View all tasks.
• Mark tasks as completed.

We’ll use the following architecture:

1. API Gateway to handle HTTP requests.
2. Lambda Functions to process business logic.
3. DynamoDB to store task data.

---

Step 1: Setting Up DynamoDB

First, we need a database to store our tasks. DynamoDB is an excellent choice because it scales automatically and provides low-latency access.

Creating a DynamoDB Table

1. Open the AWS Management Console and navigate to DynamoDB .
2. Click Create Table .
   • Table Name : TodoList
   • Primary Key : id (String)
3. Enable Auto Scaling for read/write capacity units to ensure the table scales based on demand.

Sample Table Structure

id (Primary Key)	task_name	status
1	Buy groceries	Pending
2	Read a book	Completed

Step 2: Creating Lambda Functions

Next, we’ll create Lambda functions to handle CRUD operations for our To-Do List application.

Lambda Function: Create Task

This function will insert a new task into the TodoList table.

import json
import boto3

dynamodb = boto3.resource('dynamodb')
table = dynamodb.Table('TodoList')

def lambda_handler(event, context):
    # Extract task details from the event
    task_name = event['task_name']

    # Generate a unique ID for the task
    import uuid
    task_id = str(uuid.uuid4())

    # Insert the task into DynamoDB
    table.put_item(
        Item={
            'id': task_id,
            'task_name': task_name,
            'status': 'Pending'
        }
    )

    return {
        'statusCode': 200,
        'body': json.dumps({'message': 'Task created successfully!', 'task_id': task_id})
    }

Lambda Function: Get All Tasks

This function retrieves all tasks from the TodoList table.

import json
import boto3

dynamodb = boto3.resource('dynamodb')
table = dynamodb.Table('TodoList')

def lambda_handler(event, context):
    # Scan the DynamoDB table
    response = table.scan()

    # Return the list of tasks
    return {
        'statusCode': 200,
        'body': json.dumps(response['Items'])
    }

Lambda Function: Update Task Status

This function updates the status of a task (e.g., mark as completed).

import json
import boto3

dynamodb = boto3.resource('dynamodb')
table = dynamodb.Table('TodoList')

def lambda_handler(event, context):
    # Extract task ID and new status from the event
    task_id = event['id']
    new_status = event['status']

    # Update the task in DynamoDB
    table.update_item(
        Key={'id': task_id},
        UpdateExpression='SET #status = :new_status',
        ExpressionAttributeNames={'#status': 'status'},
        ExpressionAttributeValues={':new_status': new_status}
    )

    return {
        'statusCode': 200,
        'body': json.dumps({'message': 'Task updated successfully!'})
    }

Step 3: Configuring API Gateway

Now that we have our Lambda functions, we’ll expose them via API Gateway.

Steps to Set Up API Gateway

1. Open the AWS Management Console and navigate to API Gateway .
2. Click Create API and select HTTP API .
3. Define the following routes:
   • POST /tasks : Maps to the “Create Task” Lambda function.
   • GET /tasks : Maps to the “Get All Tasks” Lambda function.
   • PUT /tasks/{id} : Maps to the “Update Task Status” Lambda function.
4. Deploy the API and note the endpoint URL.

Step 4: Testing the Application

Once everything is set up, you can test the application using tools like Postman or cURL .

Example Requests

1. Create a Task

curl -X POST https://<api-id>.execute-api.<region>.amazonaws.com/tasks \
-H "Content-Type: application/json" \
-d '{"task_name": "Buy groceries"}'

Get All Tasks

curl -X GET https://<api-id>.execute-api.<region>.amazonaws.com/tasks

Update Task Status

curl -X PUT https://<api-id>.execute-api.<region>.amazonaws.com/tasks/<task-id> \
-H "Content-Type: application/json" \
-d '{"status": "Completed"}'

Benefits of This Architecture

1. Scalability : DynamoDB and Lambda automatically scale to handle varying loads.
2. Cost Efficiency : You only pay for the compute time and storage you use.
3. Low Maintenance : AWS manages the underlying infrastructure, reducing operational overhead.


Enjoy the cloud 😁
