One of the most overlooked problems in multi-cloud environments is secrets management across providers. Teams usually solve it badly: they store the same secret in both clouds manually, forget to rotate one of them, and find out during an outage that the credentials have been out of sync for three months.
In this post I will walk through building an automated secrets synchronization pipeline between AWS Secrets Manager and OCI Vault. When a secret rotates in AWS, the pipeline detects the rotation event, retrieves the new value, and pushes it into OCI Vault automatically. Everything is built with Terraform, an AWS Lambda function, and OCI IAM. No manual steps after the initial deployment.
This is a pattern I have used in environments where the database layer runs on OCI (leveraging Oracle Database pricing and performance) while the application layer runs on AWS. Both sides need the same database credentials, and both sides need to stay in sync without human intervention.
Architecture
The flow works like this:
AWS Secrets Manager rotation event fires via EventBridge, which triggers a Lambda function. The Lambda retrieves the new secret value, authenticates to OCI using an API key stored in its own environment (not hardcoded), and calls the OCI Vault API to update the corresponding secret version. OCI Vault stores the new value and makes it available to workloads running in OCI.
Prerequisites
Before starting you need:
- AWS account with permissions to manage Secrets Manager, Lambda, EventBridge, and IAM
- OCI tenancy with permissions to manage Vault, Keys, and IAM policies
- Terraform 1.5 or later
- Python 3.11 for the Lambda function
- An existing OCI Vault and master encryption key (or we will create one)
Step 1: OCI Vault and IAM Setup
Start with OCI. We need a Vault, a master key, and an IAM user whose API key the Lambda will use to authenticate.
hcl
# OCI Vaultresource "oci_kms_vault" "app_vault" { compartment_id = var.compartment_id display_name = "multi-cloud-secrets-vault" vault_type = "DEFAULT"}# Master Encryption Key inside the Vaultresource "oci_kms_key" "secrets_key" { compartment_id = var.compartment_id display_name = "secrets-master-key" management_endpoint = oci_kms_vault.app_vault.management_endpoint key_shape { algorithm = "AES" length = 32 }}# IAM user for cross-cloud accessresource "oci_identity_user" "sync_user" { compartment_id = var.tenancy_ocid name = "aws-secrets-sync-user" description = "Service user for AWS Lambda to push secrets into OCI Vault" email = "sync-user@internal.example.com"}# API key for the sync user (you will generate the actual key pair separately)resource "oci_identity_api_key" "sync_user_key" { user_id = oci_identity_user.sync_user.id key_value = var.oci_sync_user_public_key_pem}# IAM group for the sync userresource "oci_identity_group" "sync_group" { compartment_id = var.tenancy_ocid name = "secrets-sync-group" description = "Group for cross-cloud secrets sync service users"}resource "oci_identity_user_group_membership" "sync_membership" { group_id = oci_identity_group.sync_group.id user_id = oci_identity_user.sync_user.id}# Minimal IAM policy - only what is needed, nothing moreresource "oci_identity_policy" "sync_policy" { compartment_id = var.compartment_id name = "secrets-sync-policy" description = "Allows sync user to manage secrets in the app vault only" statements = [ "Allow group secrets-sync-group to manage secret-family in compartment id ${var.compartment_id} where target.vault.id = '${oci_kms_vault.app_vault.id}'", "Allow group secrets-sync-group to use keys in compartment id ${var.compartment_id} where target.key.id = '${oci_kms_key.secrets_key.id}'" ]}
The policy scope is intentionally narrow. The sync user can only manage secrets inside this specific vault and can only use this specific key. If the AWS Lambda credentials are ever compromised, the blast radius is limited to this vault.
Step 2: Create the Initial Secret in OCI Vault
We need a secret placeholder in OCI Vault that the Lambda will update. The initial value does not matter since it will be overwritten on the first sync.
hcl
resource "oci_vault_secret" "db_password" { compartment_id = var.compartment_id vault_id = oci_kms_vault.app_vault.id key_id = oci_kms_key.secrets_key.id secret_name = "prod-db-password" secret_content { content_type = "BASE64" content = base64encode("initial-placeholder-value") name = "v1" stage = "CURRENT" } metadata = { source = "aws-secrets-manager" aws_secret = "prod/database/password" environment = "production" }}
Step 3: AWS Secrets Manager and the Source Secret
On the AWS side, create the authoritative secret and enable automatic rotation.
hcl
resource "aws_secretsmanager_secret" "db_password" { name = "prod/database/password" description = "Production database password - synced to OCI Vault" recovery_window_in_days = 7 tags = { Environment = "production" SyncTarget = "oci-vault" OciSecretName = "prod-db-password" }}resource "aws_secretsmanager_secret_version" "db_password_v1" { secret_id = aws_secretsmanager_secret.db_password.id secret_string = jsonencode({ username = "db_admin", password = var.initial_db_password, host = var.db_host, port = 1521, database = "PRODDB" })}# Rotation configuration - rotate every 30 daysresource "aws_secretsmanager_secret_rotation" "db_password_rotation" { secret_id = aws_secretsmanager_secret.db_password.id rotation_lambda_arn = aws_lambda_function.db_rotation_lambda.arn rotation_rules { automatically_after_days = 30 }}
Step 4: Store OCI Credentials in AWS Secrets Manager
The Lambda needs OCI API credentials to authenticate. Store them as a secret in AWS Secrets Manager so they never appear in Lambda environment variables in plaintext.
hcl
resource "aws_secretsmanager_secret" "oci_credentials" { name = "internal/oci-sync-credentials" description = "OCI API key credentials for secrets sync Lambda" tags = { Environment = "production" Purpose = "cross-cloud-sync" }}resource "aws_secretsmanager_secret_version" "oci_credentials_v1" { secret_id = aws_secretsmanager_secret.oci_credentials.id secret_string = jsonencode({ tenancy_ocid = var.oci_tenancy_ocid, user_ocid = var.oci_sync_user_ocid, fingerprint = var.oci_api_key_fingerprint, private_key = var.oci_private_key_pem, region = var.oci_region })}
Step 5: The Lambda Function
This is the core of the pipeline. The Lambda retrieves the rotated secret from AWS Secrets Manager, loads OCI credentials from its own secrets store, and calls the OCI Vault API to create a new secret version.
python
import boto3import jsonimport base64import ociimport loggingimport osfrom datetime import datetime, timezonefrom botocore.exceptions import ClientErrorlogger = logging.getLogger()logger.setLevel(logging.INFO)def get_oci_config(): """Retrieve OCI credentials from AWS Secrets Manager.""" client = boto3.client("secretsmanager", region_name=os.environ["AWS_REGION"]) try: response = client.get_secret_value( SecretId=os.environ["OCI_CREDENTIALS_SECRET_ARN"] ) creds = json.loads(response["SecretString"]) return { "tenancy": creds["tenancy_ocid"], "user": creds["user_ocid"], "fingerprint": creds["fingerprint"], "key_content": creds["private_key"], "region": creds["region"] } except ClientError as e: logger.error(f"Failed to retrieve OCI credentials: {e}") raisedef get_aws_secret(secret_arn: str) -> str: """Retrieve the current value of an AWS secret.""" client = boto3.client("secretsmanager", region_name=os.environ["AWS_REGION"]) try: response = client.get_secret_value(SecretId=secret_arn) return response.get("SecretString") or base64.b64decode( response["SecretBinary"] ).decode("utf-8") except ClientError as e: logger.error(f"Failed to retrieve AWS secret {secret_arn}: {e}") raisedef push_to_oci_vault( oci_config: dict, vault_id: str, key_id: str, secret_ocid: str, secret_value: str): """Create a new version of an OCI Vault secret.""" vaults_client = oci.vault.VaultsClient(oci_config) encoded_value = base64.b64encode(secret_value.encode("utf-8")).decode("utf-8") update_details = oci.vault.models.UpdateSecretDetails( secret_content=oci.vault.models.Base64SecretContentDetails( content_type=oci.vault.models.SecretContentDetails.CONTENT_TYPE_BASE64, content=encoded_value, name=f"sync-{datetime.now(timezone.utc).strftime('%Y%m%d%H%M%S')}", stage="CURRENT" ), metadata={ "synced_from": "aws-secrets-manager", "synced_at": datetime.now(timezone.utc).isoformat() } ) response = vaults_client.update_secret( secret_id=secret_ocid, update_secret_details=update_details ) logger.info( f"OCI secret updated. OCID: {secret_ocid}, " f"New version: {response.data.current_version_number}" ) return response.datadef handler(event, context): """ EventBridge trigger handler. Expects event detail to contain: - aws_secret_arn: ARN of the rotated AWS secret - oci_secret_ocid: OCID of the target OCI Vault secret - oci_vault_id: OCID of the target OCI Vault - oci_key_id: OCID of the OCI KMS key """ logger.info(f"Received event: {json.dumps(event)}") detail = event.get("detail", {}) aws_secret_arn = detail.get("aws_secret_arn") oci_secret_ocid = detail.get("oci_secret_ocid") oci_vault_id = detail.get("oci_vault_id") oci_key_id = detail.get("oci_key_id") if not all([aws_secret_arn, oci_secret_ocid, oci_vault_id, oci_key_id]): logger.error("Missing required fields in event detail") raise ValueError("Event detail must include aws_secret_arn, oci_secret_ocid, oci_vault_id, oci_key_id") logger.info(f"Syncing secret: {aws_secret_arn} to OCI: {oci_secret_ocid}") # Step 1: Get OCI credentials oci_config = get_oci_config() # Step 2: Retrieve the rotated AWS secret secret_value = get_aws_secret(aws_secret_arn) # Step 3: Push to OCI Vault result = push_to_oci_vault( oci_config=oci_config, vault_id=oci_vault_id, key_id=oci_key_id, secret_ocid=oci_secret_ocid, secret_value=secret_value ) return { "statusCode": 200, "body": { "message": "Secret synced successfully", "oci_secret_ocid": oci_secret_ocid, "oci_version": result.current_version_number } }
Step 6: Lambda IAM Role and Deployment
hcl
data "aws_iam_policy_document" "lambda_assume_role" { statement { effect = "Allow" actions = ["sts:AssumeRole"] principals { type = "Service" identifiers = ["lambda.amazonaws.com"] } }}data "aws_iam_policy_document" "lambda_permissions" { statement { effect = "Allow" actions = [ "secretsmanager:GetSecretValue", "secretsmanager:DescribeSecret" ] resources = [ aws_secretsmanager_secret.db_password.arn, aws_secretsmanager_secret.oci_credentials.arn ] } statement { effect = "Allow" actions = [ "logs:CreateLogGroup", "logs:CreateLogStream", "logs:PutLogEvents" ] resources = ["arn:aws:logs:*:*:*"] }}resource "aws_iam_role" "sync_lambda_role" { name = "secrets-sync-lambda-role" assume_role_policy = data.aws_iam_policy_document.lambda_assume_role.json}resource "aws_iam_role_policy" "sync_lambda_policy" { name = "secrets-sync-lambda-policy" role = aws_iam_role.sync_lambda_role.id policy = data.aws_iam_policy_document.lambda_permissions.json}resource "aws_lambda_function" "secrets_sync" { filename = "${path.module}/lambda/secrets_sync.zip" function_name = "oci-secrets-sync" role = aws_iam_role.sync_lambda_role.arn handler = "main.handler" runtime = "python3.11" timeout = 60 memory_size = 256 source_code_hash = filebase64sha256("${path.module}/lambda/secrets_sync.zip") environment { variables = { OCI_CREDENTIALS_SECRET_ARN = aws_secretsmanager_secret.oci_credentials.arn AWS_REGION = var.aws_region } } layers = [aws_lambda_layer_version.oci_sdk_layer.arn]}
Bundle the OCI Python SDK as a Lambda Layer so the function does not need to package it inline:
bash
mkdir -p lambda_layer/pythonpip install oci --target lambda_layer/pythoncd lambda_layer && zip -r ../oci_sdk_layer.zip python/
hcl
resource "aws_lambda_layer_version" "oci_sdk_layer" { filename = "${path.module}/oci_sdk_layer.zip" layer_name = "oci-python-sdk" compatible_runtimes = ["python3.11"] source_code_hash = filebase64sha256("${path.module}/oci_sdk_layer.zip")}
Step 7: EventBridge Rule to Trigger on Rotation
hcl
resource "aws_cloudwatch_event_rule" "secret_rotation_rule" { name = "detect-secret-rotation" description = "Fires when a Secrets Manager secret rotation completes" event_pattern = jsonencode({ source = ["aws.secretsmanager"], detail-type = ["AWS API Call via CloudTrail"], detail = { eventSource = ["secretsmanager.amazonaws.com"], eventName = ["RotateSecret", "PutSecretValue"] } })}resource "aws_cloudwatch_event_target" "sync_lambda_target" { rule = aws_cloudwatch_event_rule.secret_rotation_rule.name target_id = "SyncToOCI" arn = aws_lambda_function.secrets_sync.arn input_transformer { input_paths = { secret_arn = "$.detail.requestParameters.secretId" } input_template = <<EOF{ "detail": { "aws_secret_arn": "<secret_arn>", "oci_secret_ocid": "${var.oci_db_password_secret_ocid}", "oci_vault_id": "${oci_kms_vault.app_vault.id}", "oci_key_id": "${oci_kms_key.secrets_key.id}" }}EOF }}resource "aws_lambda_permission" "allow_eventbridge" { statement_id = "AllowEventBridgeInvoke" action = "lambda:InvokeFunction" function_name = aws_lambda_function.secrets_sync.function_name principal = "events.amazonaws.com" source_arn = aws_cloudwatch_event_rule.secret_rotation_rule.arn}
Step 8: Verifying the Pipeline
Manually trigger a rotation to test the full pipeline without waiting 30 days:
bash
# Force a rotation in AWSaws secretsmanager rotate-secret \ --secret-id prod/database/password \ --region us-east-1# Check Lambda execution logsaws logs tail /aws/lambda/oci-secrets-sync --follow# Verify the new version appeared in OCI Vaultoci vault secret get \ --secret-id <your-oci-secret-ocid> \ --query 'data.{name:secret-name, version:"current-version-number", updated:"time-of-current-version-need-rotation"}' \ --output table
A successful sync produces output similar to this in the Lambda logs:
INFO: Syncing secret: arn:aws:secretsmanager:us-east-1:123456789:secret:prod/database/password to OCI: ocid1.vaultsecret.oc1...INFO: OCI secret updated. OCID: ocid1.vaultsecret.oc1..., New version: 3
Handling Failures and Drift
The pipeline as built is synchronous and event-driven, which means if the Lambda fails, the OCI secret does not get updated. Add a dead-letter queue and a reconciliation function that runs on a schedule to catch any drift.
hcl
resource "aws_sqs_queue" "sync_dlq" { name = "secrets-sync-dlq" message_retention_seconds = 86400}resource "aws_lambda_function_event_invoke_config" "sync_retry" { function_name = aws_lambda_function.secrets_sync.function_name maximum_retry_attempts = 2 maximum_event_age_in_seconds = 300 destination_config { on_failure { destination = aws_sqs_queue.sync_dlq.arn } }}
For reconciliation, a scheduled Lambda that runs every hour compares the LastRotatedDate on the AWS secret against the synced_at metadata tag on the OCI secret. If they differ by more than five minutes, it triggers a forced sync.
Security Considerations
A few things to keep in mind when running this in production.
The OCI private key stored in AWS Secrets Manager should be rotated periodically, just like any other credential. Add it to your rotation schedule.
Enable CloudTrail in AWS and OCI Audit logging so every access to both secrets stores is recorded. If something is off with the sync, the audit logs tell you exactly which principal made the change and when.
Use VPC endpoints for Secrets Manager in AWS so the Lambda traffic never crosses the public internet when retrieving credentials.
On the OCI side, enable Vault audit logging to the OCI Logging service so every secret version write is captured.
Wrapping Up
This pipeline solves a real operational problem without requiring a third-party secrets broker. AWS Secrets Manager stays the authoritative source. OCI Vault stays current automatically. The only manual step is the initial deployment.
The pattern extends to other cross-cloud credential types. Database connection strings, API tokens, TLS certificates — any secret that needs to exist on both clouds can follow the same EventBridge to Lambda to OCI Vault flow. Extend the Lambda to support a mapping table of AWS secret ARNs to OCI secret OCIDs and one function handles your entire secrets estate across both providers.
